Specifications:
Sizes | DN 8 to DN 100 Full Bore, Reduced Bore |
Max. pressure* | 100 bar |
Temp. range | -196°C to +200°C |
Type of connections | Butt weld, Socket weld, Draad (NPT en BSP), Flens |
Standards | ISO, ASME, DIN, SMS, S10, S40 |
Material | – Body, Ball, Connections: 1.4409 (316L) – Seat: TF 3215 (PTFE + Carbon) |
Operation | manual or actuator (electric or pneumatic) |
Certificaten | 3.1, CE (PED), NEN-EN 1626:2008 |
* Max. pressure depends on the temperature and bore size. See the Pressure/Temperature diagram for more information.
Documents:
Datasheet PY4 CY FS Fire safe
English 374 KB ver. 15.0
Declaration EN ISO 10497 PY4-CY FS (Fire Safe Test)
English 838 KB ver. LYO 1400175/1
